Hydraulic Rubber Floor Mats Cutting Machine (HG-A30T)

Products

Hydraulic Rubber Floor Mats Cutting Machine (HG-A30T)

Hydraulic Rubber Floor Mats Cutting Machine (HG-A30T)

Hydraulic Rubber Floor Mats Cutting Machine (HG-A30T) Used for die cutting shoes,suitcases,bags,cases,seat covers,facial

Send your inquiry

DESCRIPTION

Basic Info
Model NO. HG-A30T
Warranty 1 Year
Control Type Artificial
Automatic Grade Semi-Automatic
Power Source Mechanical
Type Rubber Cutting Machine
Product Name Rubber Floor Mats Cutting Machine
The Warranty 1years
Custom Made Yes
Stroke 50-160mm or 50-240mm
Cutting Area 610*1600mm or 610*1220
Cutting Force 25tons~100tons
Status in Stock
Color Customized
Working System Both Hands Manual
Suitable for Material Garment,Shoes,Leather,Foam,Plastic,EVA/PU etc.
Transport Package Plastic Film or Packed in Wooden Cases
Specification CE
Trademark Honggang
Origin Guangdong of China
HS Code 847780000
Production Capacity 3000sets/Years
Product Description
Hydraulic Rubber Floor Mats Cutting Machine (HG-A30T)
Used for die cutting shoes,suitcases,bags,cases,seat covers,facial mask,soft toys,cleaning sponges,artifical flower,EPE,EVA,blister and abrasive tools.

1.Features and Advantages

1.Double-cylinders,four-columns,self-balancing connecting rod which can maintain equal pressure of each position.
2.Series B machine has the long-stroke setting for adopt to the jumbo-size materials and high knife mould cutting.
3.When the upper board pressure down and contact to the blade,automatically,it can cut slowly,so that there is no size error between the top and the bottom materials.
4.The unique setting construction,combine with the cutting knife and cutting height which stroke simple and accurate.
5.Central automatic lubrication systems can ensure precision and durability of the machine.
6.More economical and 2 or 3 times improving producting capacity.
7.Suitable for single-layer or multi-layer sheet or roll materials.

2.Product Specification

ModelCutting ForceDimension/(mm)Cutting AreaMoterStrokeNet Weight
HG-A30T/63''30 Tons2330*1320*1260610*1600mm2.2kw50-160mm1900kg
HG-B30T/48''30 Tons1950*1320*1260610*1220mm2.2kw50-240mm2000kg
HG-B30T/63''30 Tons2330*1320*1260610*1600mm2.2kw50-240mm1900kg
HG-A40T/63''40 Tons2330*1320*1260610*1600mm4kw50-240mm2500kg
HG-B40T/48''40 Tons1950*1320*1260610*1220mm4kw50-160mm2400kg
HG-A50T/63''50 Tons2330*1320*1260610*1600mm4kw50-240mm2900kg
HG-B50T/48''50 Tons1950*1320*1260610*1220mm4kw50-160mm2800kg
Remark:Cutting force and area can be as request;A and B series have different stroke for different thickness of materials.

3. The Cutting Machine Working Show

4. Application Materials:

The Cutting Machine is widely used in industrial leather,plastic,rubber,sponge,foam,EVA,PVC,cardboard,paper products,fabric,home textiles,packaging materials,non woven,carpet,car cushion,felt,synthetic materials,and other non-metallic materials in various industries;Extremely suitable for cutting multiple layers of material at one time,etc.

5. FQA:

1)What's warranty of machine?

12 months WarrantyLife-long maintenance service for machine

2)What's your after-sales service?

Engineer available to serve machines over seas;

Email and calling service in working hour; 24 hours door to door in domestic.

3)Can we test the our material by your machine free?

Yes, please contact us to send your matrial.

4)How to confirm how much ton pressure is fine?

Always 1m knife line need about 5 ton pressure.

please send your drawing or product photo, we can help you confirm.

5)Can you make dies & PP boards?

Yes, just send your drawing or material.

PP board will come with machine to you.

6)Are you a factory or trading company? We are a factory and manufacturer

7)Don't know how many ton you need?

Please contact us!

If you are not sure if your material can be cut by this cutting machine,we want to know the product information:

Material:
Max. material width:
Max. material thickness:
Max.cutting length:

Send your Inquiry Details in the Below,Click "Send"!

we will reply within 24h!
