DESCRIPTION

Basic Info

Model NO.	FAY1022
Automatic Grade	Automatic
Name	Printing Slotting Die Cutting Machine
Grade	Full Automatic
Colors	1-6
Model	1224
Max Cardboard Size	1200*2400
Min Cardboard Size	350*720
Design Speed	350 PCS/Min
Working Speed	320 PCS /Min
Cardboard Thickness	1.5-10mm
Anilox Roller Type	Ceramic
Transport Package	Container
Specification	922 1224 1226 1424 1426
Trademark	XINGLONG
Origin	Hebei, China
HS Code	8441309000
Production Capacity	200 Sets Per Year

Product Description

Box Making Machine Corrugated Carton Cardboard box printing slotting die cutting Machine

Model	AYKM922	AYKM1224	AYKM1426
Machine inside width(mm)	2400	2600	2800
Max feeding paper siz(mm)	900mm*2200mm	1200mm*2400mm	1400mm*2600mm
Max effective printing size(mm)	900mm*2000mm	1200mm*2200mm	1400mm*2400mm
Min coverage size(mm)	400*720mm	350mm*720mm	350mm*720mm
Max effective die cutting size(mm)	900*2150mm	1200mm*2350mm	1400mm*2500mm
Design speed(pcs/min)	150pcs/min	150pcs/min	150pcs/min
Working speed(pcs/min)	100-120 pcs/min	100-120pcs/min	80-100pcs/min
Standard Thickness of printing plate	4-6mm	4-6mm	4-6mm
Printing precision	±0.5mm	±0.5mm	±0.5mm
Thickness of cardboard	1.2-9mm	1.2-9mm	1.2-9mm
Walll thickness	40mm	40mm	40mm
Main motor power	15kw	15kw	15kw
Lpi of anilox roller	200/220/250	200/220/250	200/220/250

servo free-pressure feeding unit1.Servo type None-pressure Lead edge feeder with vacuum suction, wind is adjustable depend on sheet, make sure feed sheet smoothly.2.Main motor with start protecting device, machine cannot run when machine units aren't lock3.Continuous or skip feeding available4.Double feed rollers wrapped with rubber, with groove prevent overpressure, reduce pressed sheet5.Left-right baffle adjusted by computer with automatic flap, back baffle adjusted by motorized, front baffle manual synchronous adjust.6.Dust clearance bush and fan to clean dust on board. Air outlet can be adjusted as per sheet size7.Machine units move by motorized and move with alarm belling to make sure safety.8.The independent electric box controls the whole machine, and each group can control the machine alone and operate more simply

vaccum transfer printing unit1. Fast change printing plate, with footstep to control cylinder rotate clockwise or anticlockwise2.Feed roller, press roller, rubber roller, anilox roller gap adjust with electric self-lock part3.Printing phase adjusted by PLC in 360degree with digital input, do when machine running or stop4.Pneumatic brake device to keep printing register fixed, when units separate or clean, brake limit gear rotate, keep original gear position.5.Pneumatic lift anilox roller for ink, motorized ink will no dry.6.Printing cylinder made of seamless steel pipe, be grinded with chrome plated, do balance treatment, running smooth and steady.7.Lift-down design( when feed sheets anilox roller down in order, stop sheet lift rollers in order)8.Double diagram pump ink, recycle automatically, Ink supply is controlled by PLC, automatic cleaning and ink addition,With filter, simple operation, easy maintenance, ink supply more stable.9.Memory function, after clean plate it back to original position10. Printing precision: +-0.5mm11.Printing cylinder horizontal move by motorized12.5 units ceramic roller with doctor blade,high printing quality13.The doctor blade adopts the pneumatic propulsion mode, the doctor blade is closer together to the ceramicroller, and the ink is more uniform14.Air suction box table adopts electric adjustment clearance, PLC control digital display,The worktable adopts centrifugal high pressure fan, and the wind force size is controlled by frequency converter. The imprint roller is refined with high quality seamless steel pipe, surface grinding and hard chromium plating.

IR drying unit1.Infrared drying system2.Infrared heating system, temperature rise quickly and stably. About 30 kw. of heating power per group3.Tmperature constant temperature control, section heating, save electric heating power.4.Temperature alarm, automatic alarm when the temperature exceeds the standard, safe and reliable.5.Strong fan circulation, make drying speed more rapid.6.Drying box pneumatic adjustment lift, easy to install and replace the lamp tube, at the same time the drying effect.

Die cutting unit

1.servo indepedently drive ,runing more stable and high precision.

2.Rubber roller: made of good quality steel, be grinded with chrome plated.

3.Do balance treatment, improve machine running steady

4.Rubber cylinder is separate with die cylinder by air cylinder when no cutting, reduce no-load and prolong blanket use-life.

5.Die roller lift-down automatic by pneumatic control( feed sheets roller go up, stop feeding roller down, make sure correct cutting for every sheets)

6.Rubber roller move 40mm in left and right, wearable average prolong use-life

7.Rubber roller rotates follow die roller by speed compensation device whatever how rubber diameter change, make sure rubber speed same as wooden die, keep cut box is consist with wooden die.

8.Planetary gear structure used for phase adjustment.

9.Phase adjustment by PLC in 360degree with digital input( can be done when run, stop or clockwise or anticlockwise)

10.Machine have repair roller to grind blanket, so it can use many times.

11.Equipped with automatic waste cleaning device, waste paper can be discharged automatically

12.Equipped with slotting knife,when produce regular carton,no need to make wooden die,easy operate and adjust, save time labor and space.

1.
Q: Are you a manufacturer, trading company or a third party?

A: We are a manufacturer, located in Mahai industrial area south of Dongguang county, Hebei province, China. Warmly welcome to visit our company.

2.
Q: What is your minimum order quantity, can you send me samples?

A: Our minimum quantity is 1 set, as our product is machinery equipment, it's difficult to send you samples, if you have any questions about the products, please feel free to contact us for more detail, we are glad to provide you more information such as specifications, video, etc.

3.
Q: How does your factory do regarding quality controlling?

A: 1) All raw material we used are environmental-friendly

2) Skillful workers care every details in handling the producing and packing process

3) Quality control department are specially responsible for quality in each process

We have been kept providing high quality products by introducing advanced technologies for over 20 years, and our products are also widely exported to many different countries including Russia, the Middle East, Africa, Southeast Asia, EU, etc, which earned us a high reputation among the customers.

4.
Q: How about the after-sale service?

A: 1) TM online for 24 hours, also contact by email, skype, MSN, whatsapp, etc.

2) To solve the problems with videos/pictures.

3) One year warranty for spare parts change.
